Optional integrated PI controller for servo stabilization applications
Auxiliary I/O port
Two electrode beam position monitors
Low current and charge measurement
With servo control option: Stabilization of double crystal monochromators for synchrotron beamline experiments by control of the crystal cage piezo motor amplifier Stabilization of beam position in charged particle or photon beamlines
Integrated High Voltage
Avoids the need for a separate external HV supply.
Precise programmable voltage control.
Choice of polarity, positive or negative, and range up to 3000V depending on the product.
Shared ground with measurement electronics to eliminate ground loops.
Short circuit protection and redundant output voltage monitoring.
Measurement data is transmitted through state-of-the-art fiber-optic cables. The benefits are numerous compared to other forms of data transmission.
Fiber-optics are immune to electrical interference
Minimal attenuation of light through fibers
Fast messaging over enormous distances
Radiation hard fiber materials
IG2 EPICS Support
Integrate device data collection and configuration into an EPICS system, without writing a single line of code using IG2.
Runs on Windows and Debian Linux
Change PV names with simple XML configuration
Connect to multiple Pyramid devices at once
Add custom scale factors and offsets on a PV basis
Never have to recompile
Professional Pyramid support for bugs and features
Configurable EPICS channel access server for G2 and G1 devices
